UL standards

• UL1598
• UL1598A
• UL8750

CSA standard

• C22.2 No. 250

Marine and wet locations, NEMA 4X, IP66

DesignLights Consortium® Qualified (pending)

• Engineered to perform in ambient temperatures from -40°C to +55°C
• Die cast aluminum LED housing provides efficient thermal path to heat sink assembly
• Vertical fin design facilitates air flow and dust shedding
• Type 4X rated
• Impact-resistant lens sealed from the outside environment provides ingress protection against water and dust
• 60,000+ hours of operation at 55°C
• Up to 116 lumens per watt
• Contractor-friendly design is ideal for both retrofit and new construction
• Yoke mount and hub mount options are available
• Available with a photocell

• Fixture housing and door frame assembly – die cast aluminum with Corro-free epoxy powder coat
• External hardware – stainless steel
• Window – tempered glass
• Gasket – silicone
